YSZ ZrO2-high Mechanical Strength Yttria Stabilized Zirconia

FOB Reference Price:Get Latest Price
$1.00 - $10.00 / Pieces | 10 Piece/Pieces Yttria Stabilized Zirconia (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Shanghai, China (Mainland)
Type:
Ceramic Parts
Application:
Industrial Ceramic
Material:
Zirconia Ceramic, Yttria Stabilized Zirconia
Model Number:
js-201
Brand Name:
JSET
Direction:
Right Hand
Density:
4.1 ~ 6.02 G/cm3
Bending Strength:
550-1200
Compressive Strength:
2500-3000
Elastic Modulus:
210-360
Vickers Hardness:
1100-1600
Thermal Conductivity:
2-27
Thermal Shock Resistance:
300/450
Max Working Temperature:
1000-2100
Supply Ability
Supply Ability:
100 Piece/Pieces per Month Yttria Stabilized Zirconia
Packaging & Delivery
Packaging Details
Yttria Stabilized Zirconia with JSET standard carton
Port
shanghai
Lead Time :
Within 30 days
Product Description

YSZ ZrO2-high Mechanical Strength Yttria Stabilized Zirconia

Reasons to choose ceramic for your parts:
Ceramic parts are used for applications that require wear or corrosion resistance, high temperature capability, or ceramic insulators for electrical resistance.
1. High wear resistance
2. High corrosion resistance
3. Electrical resistance
4. Low thermal expansion
5. High tensile strength
6. Dielectric strength

Product Name
YSZ ZrO2-high Mechanical Strength Yttria Stabilized Zirconia
Material
Yttria Stabilized Zirconia
Color
white, yellow, black, blue
Standard
ISO 2768, or customized
Used
for industrial use
Products Show
Product Description
DATASHEET of ZIRCONIA
Main Characteristics
High Mechanical Strength, Good Wear and Heat Resistance.
Main Applications
Wear and Heat Resistance Parts
Zirconia (ZrO2)
Zirconid-Toughened Alumina
MgO Partially Stabilized Zirconia
3%mol Y2O3 Stabilized Zirconia
Characteristics
Item
ZTA
Mg-PSZ
3Y-TZP
Unit
Mechanical Characteristics
Colour
White
Ivory
White/Ivory

Density
4.1
5.72
6.02
g/cm3
Bending Strength
550
500
1200
MPa
Compressive Strength
2900
2500
3000
MPa
Elastic Modulus
360
250
210
GPa
Fracture Toughness
5~6
8
13
MPam1/2
Vickers Hardness
1600
1100
1300
HV0.5
Thermal Characteristics
Coefficient of Line Thermal Expansion
8.3
10.2
10.3
10-6K-1
Thermal Conductivity
27
3
2.2
W/mK
Thermal Shock Resistance
(Put in Water)
300
450
300
∆T°C
Max Working Temperature
1500
2100
1000
°C
Electrical Characteristics
Volume Resistance at 20°C
>1014
>1013
>1013
Ωcm
Dielectric Strength
9×106
13×105
11×106
V/m
Dielectric Constant
10.6
28
33
εr
One MHZ Dielectric
Loss Angle at 20°C
0.0005
0.0017
0.0016
tanδ
Products Show
Our Service

High quality

Passed the ISO9001:2008 quality system authentication and ROHS authentication.

High quality

Passed the ISO9001:2008 quality system authentication and ROHS authentication.

High quality

Passed the ISO9001:2008 quality system authentication and ROHS authentication.

Our Company

Factory

Our Factory

Workshop

Our Workshop

Solutions With Innovation


Team

Our Team

Packing & Delivery
Packaging
Size
123 (L) * 456 (W) * 789 (D)
Weight
1.2 kg



Packaging Details
The normal package is vacuum package, then put in a carton for international express. If ship by sea we will prepare wooden box for better insurance.
Packaging
Size
123 (L) * 456 (W) * 789 (D)
Weight
50kgs



Packaging Details
wooden box for shipping by sea.
We will use PE film to protect the ceramic products.
We can also pack it according to customers special request.
FAQ

Q: Are you trading company or manufacturer ?

A: We are factory.

Q: How long is your delivery time?

A: Generally it is 5-10 days if the goods are in stock. or it is 30-45 days if the goods are not in stock, it is according to quantity.

Q: Do you provide samples ? is it free or extra ?

A: Yes, we could offer the sample for free charge but do not pay the cost of freight.

Q: What is your terms of payment ?

A: 100% in advance.
