High hardness precision grind silicon nitride

FOB Reference Price:Get Latest Price
$1.00 - $10.00 / Pieces | 3 Piece/Pieces (Min. Order)
Lead Time:
Quantity(Pieces) 1 - 1000 >1000
Est. Time(days) 35 Negotiable
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Shanghai, China
Type:
Ceramic Parts
Application:
Industrial Ceramic
Material:
Zirconia Ceramic
Model Number:
Customization
Brand Name:
JSET
Product name:
precision grind silicon nitride
Colour:
Black
Flexual Strength:
720 MPa
Compressive Strength:
3,800MPa
Elastic Modulus:
300 GPa
Weber Coefficient:
15M
Vickers Hardness:
1,700HV0.5
Thermal Conductivity:
21W/mK
Max Working Temperature:
1,300°C
Supply Ability
Supply Ability:
1000 Piece/Pieces per Month precision grind silicon nitride
Packaging & Delivery
Packaging Details
High hardness precision grind silicon nitride
OUR STANDARD CARTONS.
Port
SHANGHAI
Lead Time :
Quantity(Pieces) 1 - 1000 >1000
Est. Time(days) 35 To be negotiated
Product Description

High hardness precision grind silicon nitride

1. .Application: Used for all kinds of electric heating equipment and electric equipment, and textile machinery.
2. Good smooth and high strength.
3. Diameter from 1mm to 120mm,Length from 100mm to 2000mm. Multi bores tubes can be made.
4. Max working temperature 1800.
5. Out surface can be grinded drilling hole to make tight tolerance and right instillation.
6.Large quantity in stock makes fast delivery and competitive prices.

7. Size: M3-48

8. Standard: DIN 315

9. Certification: ISO9001, SGS, CTI, ROHS

Product Name
High hardness precision grind silicon nitride
Material
Si3N4 silicon nitride
Color
black
Standard
DIN GB ISO JIS BA ANSI
Used
industry machinery
Products Show
Product Description
DATASHEET of SiN
Main Characteristics
Light Weight, High Wear & Heat Resistance
Main Applications
Heat, Wear and Corrosion Resistance Parts
Silicon Nitride (Si3N4)
Characteristics
Item
Value
Unit
Mechanical Characteristics
Colour
Gray/Black
Density
3.23
g/cm3
Flexural Strength
720
MPa
Compressive Strength
3800
MPa
Elastic Modulus
300
GPa
Fracture Toughness
6.7
MPam1/2
Weber Coefficient
15
M
Vickers Hardness
1700
HV0.5
Thermal Characteristics
Coefficient of Line Thermal Expansion
3
10-6K-1
Thermal Conductivity(20°C)
21
W/mK
Thermal Shock Resistance (Put in Water)
750
∆T°C
Max Working Temperature
1300
°C
Electrical Characteristics
Volume Resistance at 20°C
>1014
Ωcm
Dielectric Strength
10×106
V/m
Dielectric Constant (1MHz)
8.6
εr
Loss Tangent
3
10-4
Products Show
Our Service

High quality

Passed the ISO9001:2008 quality system authentication and ROHS authentication.

High quality

Passed the ISO9001:2008 quality system authentication and ROHS authentication.

High quality

Passed the ISO9001:2008 quality system authentication and ROHS authentication.

Packing & Delivery

Packing Details  : Packing, ceramic parts customized, 50pcs/carton or as requested.

Delivery Details : about 30 days after order of ceramic parts / ceramic pressure sensor / tube / rob / disk / sheets / insulator / connector / bolt / nut / washer / crucible /  component, etc.

1. Special logistics packaging
2. Shock bubble film
3. Suitable carton size
Our Company

Factory

Our Factory

Workshop

Our Workshop

Warehouse

Our Warehouse

Products

High quality

FAQ

Q: Are you trading company or manufacturer ?

A: Yes, JSET is a trading company, but we have 3 ceramic product engineers with 8 years experience in ceramic industry. We do business with many ceramic factories/plants, we can give you best price and quality for the same products. And we can reduce delivery time through effective communication.

Q: What is necessary for a quote?
A: Your drawing if possible, quantity, tolerance requirements, etc.


Q: And shipment?
A: For small quantity it is shipped by International express.For big quantity will be shipped by sea.

Q: How long is your delivery time?

A: Generally it is 5-10 days if the goods are in stock. or it is 20-30 days if the goods are not in stock, it is according to quantity.

Q: What is your terms of payment ?

A: 100% T/T in advance.
